Construction waterstops, internal in accordance with factory standard

Series A
ProduCt a (mm) b (mm) c (mm) d (mm) qty. stop anchors Material
A 10 100 20 3 2,5 - PVC-P
A 11 110 25 3 2,5 - PVC-P
A 15 150 45 3 2,5 - PVC-P
A 19 190 70 3 2,5 - PVC-P
A 24 240 80 3,5 2,5 - PVC-P
A 32 320 100 4,5 3 - PVC-P
A 50 500 150 6 3,5 - PVC-P



Data sheets

Further information can be found in the accompanying data sheets:
deutsch
english



Series Flex
ProduCt a (mm) c (mm) qty. stop anchors Material
Flex 10 100 4,5 - PVC-P reinforced
Flex 15 150 4,5 - PVC-P reinforced
Flex 19 190 4,5 - PVC-P reinforced
Flex 24 240 4,5 - PVC-P reinforced
Flex 32 320 5 - PVC-P reinforced

reinforced

Data sheets

Further information can be found in the accompanying data sheets:
deutsch
english



Series A SM
ProduCt a (mm) b (mm) c (mm) d (mm) e (mm) qty. stop anchors Material
A 15 SM 150 4,3 18 130 5,5 - PVC-P reinforced

reinforced

Data sheets

Further information can be found in the accompanying data sheets:
deutsch
english
